VW plug&play cable set for Mid Line Rear Camera

Suitable for Golf 7 5G0

• Showing the rear area in the Headunit screen
• Automatic display switch by rear gear
• Much easier orientation due to the guiding lines and fields which are integrated into the video picture and change depending on the steering wheel angle
• Two modes are available:
• parkingmode 1 (Transverse parking): Useful to park into a slot which is transverse to the driving direction on for reverse driving into a longer entry
• parkingmode 2 (Longitudinal parking): Useful for parking into a slot along the driving direction on a curb

Compatible with head unit :

• Navigationssystem: Discover Media
• Navigationssystem: Discover Pro
• Radiosystem: Composition Media
• • Not compatible with Composition Media with the following part numbers :
  • 5G0035820A
  • 5G0035820
  • 5G0035819A
  • 5G0035819
  • 5G0035812




Lenght : 650cm  - from head unit to module and from module to camera

Camera, control unit as well as mounting plate will be needed in addition

Parts needed in addition:

• Camera 5G0827469CFOD

• Module 5Q0907441



No fitting/coding instruction available
